How to Install Solera Smart Arm IR Sensor on RV Awning V1 YouTube

The Solera (R) Smart Arm ™ incorporates several intelligent features sure to enhance everyone's camping experience. Best of all, these new features are all accessible from a weatherproof controller built right into the awning arm itself, making for easy and convenient access without having to go inside the RV to operate the switches.. To get power to the controller of your Solera Smart Arm 12V Power RV Awning part # LC759404, you need to tap into an existing circuit, or run a power wire from the battery with an inline fuse holder, and a 15 amp fuse, like part # SWC9538, and part # C58450-1. The red "POWER" wire on the motor or awning head, attaches to the red power wire on the controller.

Page 8: Solera Smart Arm Awning Solera Awning ® Smart Arm Installation and Owner's Manual (For Aftermarket Applications) 4. Snap Wind Sensor (Fig.11 and Fig.12) in place with wires 6. Insert the IR Sensor (Fig.13) into the bottom of the toward coach Smart Arm Touch Pad (Fig.15), with the white sensor facing out. Page 9: Adjusting Pitch. Rev: 08.21.18 Page 2 CCD-0001985 SOLERA ® SMART ARM AWNING CONTROLLER REPLACEMENT Sszçrwr ãräu Installation NotE: Steps 1 and 2 pertain to connecting the IR sensor to the smart arm controller.If not equipped with the IR sensor, skip to step 3. 1. Remove the protective tape (Fig. 3) covering the connection pins at the bottom of the smart arm controller.
